Jeep Vehicle Wheelbase Chart & Specs by Model | XT
All Jeep Vehicle Wheelbase Information
A wheelbase is the measure of distance between the centers of the front and rear axles. A Jeep’s wheelbase is important because it affects balance and steering. A longer wheelbase typically provides a smoother ride, while a short wheelbase enables a vehicle to take on corners faster. Use this chart to determine the length of your Jeep’s wheelbase. Whether you’ve got a 2 or 4-door, easily reference the difference between an Unlimited Jeep wrangler wheelbase and 2-door wheelbase. Also find wheelbase lengths for the:
- Cherokee
- Grand Cherokee
- Comanche
- Compass
- CJ-8
- And more.
MODEL* |
WHEELBASE IN INCHES* |
|---|---|
| Wrangler JK (2007-2011) 2door/4door | 95.4/116 |
| Wrangler TJ (1997-2006) | 93.4 |
| Wrangler YJ (1987-1995) | 93.4 |
| Grand Cherokee (WJ/ZJ) (1993-2011) | 105.9 |
| Cherokee (XJ) (1984-2001) | 101.4 |
| Comanche MJ (1986-1992) short bed/long bed) | 113/119.9 |
| Commander (2006-2010) | 109.5 |
| Compass (2007-2011) | 103.7 |
| Liberty (2002-2011) KJ/KK | 104.2/106.1 |
| CJ-8 (1981-1986) | 103.5 |
| CJ-7 (1976-1986) | 93.5 |
| CJ-6 (1972-1981) | 103.5 |
| CJ-6 (1955-1971) | 101 |
| CJ-5 (1972-1986) | 83.5 |
| CJ-5 (1955-1971) | 81 |
| GPW, MB, CJ-2A, CJ-3A, CJ-3B, M-38 | 80 |
| M-715 | 126 |
| J10, J20 long bed/short bed | 131/119 |
| Wagoneer (1971-1991) | 109 |
| Wagoneer (1963-1970) | 110 |
| Jeepster (1972-1973) | 104 |
| Jeepster (1967-1971) | 101 |
| J-2000 | 120 |
| J-3000 | 126 |
| J-3800 | 132 |
| Willys Wagon | 104 |
| Willys Truck | 118 |
*Updated Model, Year Range and Wheelbase Information
