How to Install Westin E-Series Step Bar - Stainless Steel on your Wrangler

1. Remove all contents from box. Verify that all parts listed are present and free from damage. Read and understand all I nstructions before attempting installation.

2. From underneath the vehicle remove tape from front slots in drivers side rocker panel.

3. Insert M10 nut plate through slot and align nut with the round hole, attach drivers side front mounting bracket using (1) M10 hex bolt, (1) M 10 washer, and (1) M10 lock nut. Do not fully tighten at this time

4. Align bracket with the holes in the pinch weld and attach with (2) M6 hex bolts, (4) M6 flat washers note: the smaller od washer is used for behind the pinch weld and the larger od flat washer is used for in front of the pinch weld. And (2) M6 nylock nuts. Do not fully tighten at this time

5. Repeat steps 2-4 for all other brackets

6. Take drivers side step bar and align it with the front and rear mounting brackets, attach the bar using (4) M8 hex nuts and (4) M8 flat washers. Do not fully tighten at this time

7. Repeat step 6 for passenger side bar

8. Align bars to fit and tighten all hardware at this time

9. Torque all M10 hardware to 25-30 ft-lbs, all M8 hardware to 15-20 ft-lbs, and all M6 hardware to 10-15 ft-lbs
