How to Install Vision X Tantrum LED Rock Light - Amber on your 87-18 Jeep Wrangler YJ, TJ, JK & JL

​CONTENTS:

8 - 2 WATT LED PODS
1 - MASTER CONTROLLER
1 -WIRELESS REMOTE
1 - INSTALLATION HARDWARE

WIRELESS OPERATION:

A) ON/OFF
B) RESET ( SOLID ON)
C) SEQUENCE/PATTERN
D) SPEED

INSTALLATION:

1) MOUNT LED PODS IN DESIRED LOCATION USING PROVIDED ADHESIVE AND SCREWS.

2) MOUNT DISTRIBUTION BLOCK ON FIREWALL.

3) RUN CORDS TO DISTRIBUTION BLOCK AND PLUG IN WATERPROOF CONNECTORS.

4) RUN MASTER CONTROLLER WIRE THROUGH FIREWALL TO INTERIOR OF VEHICLE.

5) MOUNT MASTER CONTROLLER AND PLUG INTO DISTRIBUTION BLOCK.

7) PLUG IN CIGARETTE LIGHTER ADAPTER OR HARDWIRE TO CONSTANT POWER SOURCE. ( BLACK/WHITE - 12VOLTS / BLACK - GROUND)

8) PRESS POWER BUTTON ON MASTER CONTROLLER TO TEST.

WARRANTY INFORMATION:

ALL VISION MOTOR SPORTS LIGHTING IS BACKED BY A FULL ONE YEAR LIMITED WARRANTY. VISION MOTOR SPORTS WARRANTS THE REPLACEMENT OF PRODUCTS TO DEFECTS IN MATERIAL AND / OR WORKMANSHIP.

THE WARRANTY APPLIES UNDER THE FOLLOWING CONDITIONS;

1) PROOF OF PURCHASE IS REQUIRED TO VALIDATE WARRANTY.

2) IMPROPER INSTALLATION, ACCIDENT, ABUSE, NEGLECT AND NORMAL WEAR ARE NOT COVERED UNDER WARRANTY.

3) BROKEN GLASS IS NOT COVERED UNDER WARRANTY.
