How to Install a Smittybilt Black Denim Front Super Seat Recliner Vinyl on your 87-18 Jeep Wrangler YJ, TJ, JK & JL
Shop Parts in this Guide
- Smittybilt Front Contour Sport Bucket Reclining Seat; Black Denim (76-02 Jeep CJ5, CJ7, Wrangler YJ & TJ)
- Smittybilt Factory Style Recliner; Charcoal Light Gray Denim (76-02 Jeep CJ5, CJ7, Wrangler YJ & TJ)
- Smittybilt Factory Style Recliner; Spice Denim (76-02 Jeep CJ5, CJ7, Wrangler YJ & TJ)
- Smittybilt Front Contour Sport Bucket Reclining Seat; Spice Denim (76-02 Jeep CJ5, CJ7, Wrangler YJ & TJ)
- Smittybilt Front Contour Sport Bucket Reclining Seat; Gray Denim (76-02 Jeep CJ5, CJ7, Wrangler YJ & TJ)
ASSEMBLY INSTRUCTIONS:
included Components:
1-Seat
1-Plastic Cover RH
1-Plastic Cover LH
1 -Recliner Knob
I. Press down (firmly) .the plastic cover over the metal brackets on each rear corner-
2. Press on the recliner knob(on the left side for the driver side, on the right side forthe
passenger side)
INSTALLATION INSTRUCTIONS:
5. Remove the old seat from the riser by loosening 4 bolts.
Save these bolts for later use.
6. Remove the slider from the old seat by loosening the 4 bolts. Save these bolts for later use.
To access the rear 2 bolts push down the arm to move slider,
7. Place the slider mechanism on the new seat.
Use the spacers from the old seat to align the slider.
8. Fasten slider to the new seat using the 4 Bolts saved from Step 5.
9. Carefully place slider assembly back onto riser, This will be difficult Fasten with 4 bolts saved from Step 4.
