How to Install Rugged Ridge Seat Protector Pair Neoprene - Tan on your 07-18 Jeep Wrangler JK; 2018 Jeep Wrangler JL

Tools Required
  • Basic Hand Tools Required
Extreme Terrain
Shop Parts in this Guide

Parts included:

(1) Front driver's side seat vest
(1) Front passenger's side seat vest

Warning: Not for use in Jeeps equiped with seat mounted air bags!


Instructions:

Step (1) Slide, and tilt back of seat forward

Step (2) Remove Head rest



Step (3) Slip vest over back of seat

Step (4) Slip lower nylon strap and clip between the upper and lower portions of the seat.


Step (5) Slip Velcro straps through lower straps plastic loops as shown.

Step (6) position the side straps in front of seat adjuster as shown. Driver's side adjust seat up as high as possible using the seat height adjuster lever. Slip straps between raised seat and seat riser. Clip straps together and adjust. DO NOT OVER TIGHTEN.

Passenger's side place the rear strap underneath the seat slider and and seat riser. Adjusting the seat forward or backwards may help with locating and pulling inner most tabs near console. The front straps should be run under the front of the seat just behind the seat slider adjustment arm. Adjust straps but DO NOT OVER TIGHTEN!


Step (7) Slide front and rear lower straps Step (7) under seat. This step is the same for both the driver's side and passenger's side seat vest. Make sure that the front straps are inserted through the front seat adjuster arm to insure proper operation of seat slider. Clip and adjust. DO NOT OVER TIGHTEN!

Step (8) Adjust all vest straps for snug fit and pull vest onto seat in desired position. Reinstall head rest and adjust seat back to desired driving position.
