How to Install Rugged Ridge Front Hard Top Sun Shade - Black (07-18 Wrangler JK) on your Jeep Wrangler

1. Carefully open the package using a box cutter or knife (Figure A) and ensure the shade is included and undamaged.

2. Toss the netting over top of the front of the vehicle (Figure B).

3. Starting with the front corner, pull the band under the roll bar and up through the other side (Figure C).

4. Using the plastic fastener, slip into place to hold corner securely (Figure D).

5. Secure the other front corner (Figure E).

6. Secure the remaining sides using the same process as Steps 3 & 4.

7. Locate the Velcro strap at the footman loop on each side (Figure F).

8. Run each Velcro strap through the footman loop and reattach (Figure G).

9. Secure the two middle Velcro straps to the center footman loop, as well (Figure H).

10. Connect each hook onto the sides of the center footman loop (Figure I).

Installation Instructions Written by ExtremeTerrain Customer J. Sandlin 05/30/2018.
