How to Install RT Off-Road LED Dome Light - White (11-18 Wrangler JK 4 Door) on your Jeep Wrangler
Shop Parts in this Guide
1. Using a plastic trim tool, remove the front dome light cover (Figure A).
Figure A
2. Locate the bulb in each dome light section (Figure B).
Figure B
3. Pull directly out on the bulb by the pinch-connection (Figure C).
Figure C
4. Remove the bulb entirely (Figure D).
Figure D
5. Repeat Steps 3-4 on the other bulb.
6. Insert the LED wiring into the pinch-connection (Figure E).
7. Remove the 3M backing from each mount and press them into the light housing (Figure F).
Figure F
8. Press both LEDs into place (Figure G).
Figure G
9. Return the dome light cover.
10. Using a plastic trim tool, remove the rear dome light cover (Figure H).
Figure H
11. Locate the bulb within the rear pinch-connection (Figure I).
Figure I
12. Remove the bulb from the rear pinch-connection (Figure J).
Figure J
13. Press the LED into the pinch-connection (Figure K).
Figure K
14. Replace the rear dome light cover(Figure L).
Figure L
Before
After
Installation Instructions Written by ExtremeTerrain Customer J. Sandlin 07/19/2018
